Tube Laser Cutting

With tube laser cutting, MÜNCH extends its sheet metal and tube processing capabilities to include the precise cutting of tubes and profiles. Based on 3D models, we create accurately fitting components for downstream processes and complex assemblies.

Scope of Services

We process all common materials within a clearly defined production range:

• Tube and profile processing up to 6,500 mm in length
• Wall thicknesses up to 6 mm
• Tube diameters or enclosing circle from 15 to 150 mm
• 3 kW laser power
• Processing of 3D models

Production-Oriented Component Design

When tube laser parts are used in welded assemblies, the component geometry is adapted to its later application at an early stage. This creates solutions that fit reliably not only in the model, but also in the actual assembly.

• Geometry adapted with the later assembly in mind
• Production-oriented refinement of models
• Integration of plug-in connections and positioning aids via software
• Simplified alignment during welding and poka-yoke support

Process Reliability Through Digital Production Support

In tube laser cutting, too, coordinated software solutions ensure structured and reproducible production processes.

• Central storage of component and program data as the basis for reliable workflows
• Reproducible production processes based on a clear data foundation
• Batch traceability from the assembly down to the individual part
